2050M

The 2050M our largest Bulldozer is fitted with our FPT 6.7 litre engine and the state of the art
hydrostatic drive system, delivering class leading drawbar pull, accuracy and fuel efficiency.

Specifications

Standard Equipment

  • FPT Industrial engine NEF Family
  • Integral engine oil cooling
  • Fuel filter
  • Dual element radial seat air cleaner
  • 120 amp alternator
  • 2 x 12 V batteries
  • Engine side panels
  • Hydraulic track adjusters
  • Case Extended Life Track (CELT)
  • Chain
  • Permanently lubricated (track and carrier rollers/idlers)
  • Track adjuster guard
  • Track guides - front and rear
  • 50°- 60° variable pitch with Integral
  • Adjustment Tool, Single Lever,
  • Electro-Hydraulic control for blade lift, angle, or tilt “Equistatic” device for dozer version
  • Cab with heater, A/C, defroster, windshield wiper and lights
  • Seat belt
  • 76 mm Internal mirror
  • Reverse gear warning
  • Horn
  • Lights: 2 in front and 1 in rear
  • Master disconnect switch
  • Mirror
  • Rear transmission guard
  • Dual path infinitely variable, singlelever controlled Hydrostatic drive with
  • Electronic
  • Straight Tracking and Counterrotation
  • Forward/reverse ratio control
  • 3 pre-selectable steering sensitivities
  • 3 reversing sensitivities
  • 3 blades sensitivities
  • Blade Shaking Mode
  • Fine grading mode
  • Triple reduction nal drive: helical gear/planetary
  • Decelerator with hydrostatic drive retardation
  • Automatic spring applied parking brake
Specifications

Optional Equipment

  • Ripper - 5 positions with 3 shanks
  • Rear tow hook
  • Rear drawbar
  • 4 spool hydraulic valve for fieldinstalled ripper
  • 3 spool hydraulic valve without plugs for field-installed ripper
  • 3 spool hydraulic valve with plugs
  • CAB canopy brush guard
  • Center rockguard
  • Sweeps
  • Cab rear screen
  • Radiator brush screen
  • Environmental drain
  • Grid heater
  • Additional work lights
  • Front pull hook
  • Rear view mirror
  • Rear wiper for cab

Solutions

CASE Care

Give your equipment the best treatment to maximize its performance, productivity and efficiency, year after year.

CASE Protect

An extended warranty is now a standard offer on all CASE Construction equipment.

CASE SiteWatchTM

Boost your machine's profitability by tracking and managing your fleet's operation.

CASE SiteConnect

Reduce your Total Cost of Ownership by increased connectivity resulting to more efficient service.

M-Series Crawler Dozers

3.66MB

Download
